EL10001

Specifications

• Peak Power: 1 x 1000W
• Power RMS 2Ω @ 14.4V: 1 x 500W
• Power RMS 4Ω @ 14.4V: 1 x 350W
• THD+N @ Nominal Power: 1%
• Frequency Response: 20Hz ~ 150Hz
• Dimensions: 8.2” W x 5.0” L x 2.1” H



• SNR: 90dB
• Input Sensitivity: 0.2V to 6V
• Damping Factor: 260
• Operating Voltage: 9V to 16V
• Low Pass Filter: 50Hz to 150Hz
• Bass Boost: Adjustable 0-12dB
• Bass Boost Center Frequency: 45Hz
