SQ40044

Specifications

• Power RMS 2Ω @ 14.4V: 4 x 100W
• Power RMS 4Ω @ 14.4V: 4 x 55W
• Bridge Power 4Ω @ 14.4V: 2 x 200W
• Bridge Power 8Ω @ 14.4V: 2 x 110W
• THD+N @ Nominal Power: <1%
• Frequency Response: 5Hz ~ 20kHz
• SNR: 88dB
• Dimensions: 5-3/16" W x 4-1/2" L x 1-7/8" H



• Input Sensitivity: 0.5V to 6V
• Damping Factor: 100
• Operating Voltage: 9V to 16V
• High Pass Filter: 45Hz to 850Hz
• Low Pass Filter: 45Hz to 850Hz
• Total Efficiency: 79%
• Max Current Draw (A): 40
• Music Current Draw (A): 20
