SQ30001

Specifications

• Power RMS 1Ω @ 12.6V: 1 x 3000W
• Power RMS 1Ω @ 14.4V: 1 x 3900W
• THD+N @ Nominal Power: 1%
• Frequency Response: 5Hz ~ 20kHz
• SNR: 84dB
• Input Sensitivity: 0.2V to 4V
• Dimensions: 9" W x 8.8" L x 3" H



• Damping Factor: >1000
• Operating Voltage: 9V to 16V
• High Pass Filter: 5Hz to 80Hz
• Low Pass Filter: 80Hz to 20kHz
• Total Efficiency: 79%
• Max Current Draw (A): 305
• Music Current Draw (A): 153
